AIG952

• Modern layered body with a mirror-finish top design
• Ergonomic grip with high-rebound button structure
• Fast reading of Barcode, QR Code, Data Matrix, PDF417, etc.
• Global shutter supports scanning moving barcodes up to 2 m/s
• Excellent performance on low-contrast, damaged, or poorly printed codes
• Plug and play, no driver required; compatible with major operating systems
• Professional electrostatic protection and anti-interference design



Light Source LED White Light                                                  Aiming Light: Green Dot
Image Sensor 640×480 pixels (Global Shutter)
CPU 1.2G Dual-core                                                      Imaging Speed: 120FPS                                                  Resolution (minimum): 3mil
Minimum Print Contrast 15% Reflective Difference                                  Motion Tolerance: 2m/s
Image Field of View D50°(H) × 38°(V)
Reading Angle Pitch ±60° / Roll ±360° / Skew ±60°
Decoding Capability 1D: All standard 1D codes including GS1 DataBar™ linear code can be automatically distinguished and decoded.
2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code, Stack code: GS1 DataBar Expanded Stacked;
GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.
Reading Indicators LED Light / Buzzer
Typical Depth of Field Precision                  Barcode                        Depth of Field
3.34mil                     CODE 128                    40 mm — 80 mm
3.34mil                     CODE 128                   40 mm — 80 mm
5mil                           CODE 128                   35 mm — 135 mm
3.34mil                     EAN-13                        40 mm — 80 mm
5mil                           EAN-13                        30 mm — 105 mm
13.34mil                   EAN-13                        30 mm — 290 mm
5mil                           PDF417                        35 mm — 105 mm
15mil                         QR                                20 mm — 155 mm
10mil                         DM                               30 mm — 140 mm
Current Working current: < 280 mA                    Standby current: 100 mA
Input Voltage 5V DC ±5% / 500mA                                  ESD Protection: Air 15kV / Contact 8kV
Drop Resistance Withstands repeated drops from 1.2m onto concrete surface
Temperature Working: -10°C to 50°C                            Storage: -20°C to 65°C                               Humidity: 5%–95% (non-condensing)
Ambient Light Indoor: 0–6000 Lux                                 Outdoor: 0–100,000 Lux
Product Size 172×67×87 mm
Interfaces USB HID, USB COM, RS232, HID POS (OPOS/JPOS), Optional interface
Transmission Support multi-language transmission, compatible with major operating systems
